Description
The 6235-C is a premium twin twist (two flavor) countertop, gravity-fed soft serve machine built for operators who need high output and versatility in a compact footprint. It is capable of producing a wide range of products including ice cream, frozen yogurt, custards, and sorbets. With patented freezing technology on its 1.8qt cylinders, the 6235-C delivers super-fast recovery times and can produce over 350 4oz servings per hour, making it a leader in its class for speed and efficiency.
At the core of its performance is Spaceman’s patented 100% Controlled Contact Flooded Evaporator, engineered for maximum efficiency to achieve the industry’s fastest freeze-down and recovery times with smaller ice crystals and the smoothest, creamiest mouthfeel. Continuous improvements in design, driven by field feedback and R&D, provide greater structural integrity, reduce failure points, and improve serviceability. The advanced V5 single-piece auger eliminates unnecessary parts, ensures 100% evaporator wall contact, reduces cleaning time, and enhances consistency with the smallest ice crystals in the industry. The dual-system gravity-fed air inlet works in tandem with the V5 auger to optimize overrun and ensure superior texture and long-term product quality.
Smart safety controls and independent standby modes maintain hopper and cylinder temperatures below 4.4ºC (40ºF), protecting product quality and conserving energy during non-use. Inverter motor control allows the use of three-phase motors with single-phase power input, reducing torque and strain by controlling start-up speed and minimizing gearbox and drivetrain failures caused by freeze-ups or operational errors. Separate hopper cooling controls independently regulate each hopper to maintain ideal temperatures, prevent sidewall freezing, and optimize output by pre-chilling mix before it enters the freezing cylinder. Dual digital user interfaces make operation simple, while hopper refrigeration and integrated agitators keep mix fresh, stirred, and dairy-safe throughout the day.
(When paired with a cart, the 6235-C also serves as a direct replacement for the 6250-C.)
Key Features:
- Over 350 4 oz servings per hour with 1.8 qt cylinders
- Patented Controlled Contact Flooded Evaporator
- V5 single-piece auger
- Dual-system gravity-fed air inlet
- Dual digital user interfaces with viscosity control
- Refrigerated hoppers with agitators
- Independent standby for hopper and cylinder maintaining below 40°F
- Separate hopper cooling controls
- Inverter motor control
- Continuous design improvements
- Reduced cleaning parts with easy installation
- Compatible with Cart-550 as replacement for 6250-C
Sizing Guide – Servings per Minute (per flavor):
- 4 oz: 3
- 8 oz: 1
- 12 oz: Not recommended
Not sure which machine fits your volume? Compare every Spaceman soft serve and frozen beverage model side by side:
📏 View the Spaceman Sizing Guide (PDF)
Specifications:
Gravity model (6235-C):
- Flavors: 2
- Cylinder volume: 1.8 qt
- Hopper volume: 12.7 qt
- Electrical: 208-230V, 1 phase, L6-20 plug
- Main compressor: 6500 BTU
- Pre-cooling compressor: 480 BTU
- Beater motor: 2 x 1.0 HP
- Dimensions: 21"W x 25.6"D x 37.6"H
- Weight: 412 lbs
- Ships from: Houston, TX
Pressurized model (6235A-C):
- Flavors: 2
- Cylinder volume: 1.8 qt
- Hopper volume: 8.5 qt
- Electrical: 208-230V, 1 phase, L6-20 plug
- Main compressor: 6500 BTU
- Pre-cooling compressor: 480 BTU
- Beater motor: 2 x 1.0 HP
- Dimensions: 21"W x 25.6"D x 37.6"H
- Weight: 436 lbs
- Ships from: Houston, TX
Gravity vs. Pressurized – Pricing:
- Gravity (6235-C): $15,954 $31,908 – mix is gravity-fed into the freezing cylinder, with a dual-system air inlet for consistent overrun.
- Pressurized (6235A-C): $17,526 $35,052 – an advanced pressurized air pump with six overrun settings and anti-starvation control lets you dial in product texture.
Delivery, Setup & Training Options:
- Free freight is included on every machine.
- Start-Up: +$375
- Installation (includes Start-Up): +$625
- Factory On-Site Training: +$900
Select your preferred option above before adding to cart.
Downloads:
- Sizing Guide (PDF)
- Spec Sheet – Gravity (PDF)
- Spec Sheet – Pressurized (PDF)
- Warranty (PDF)
- Operator Manual (PDF)
- Cleaning Guide (PDF)
Warranty:
- 1 Year Parts & Labor
- 5 Years Compressor/Hopper/Shell
- Remote Training
- Fastest Average Nationwide Service Response
