Across International
Price:
$7,290.00

Description

The Across International 22 Cu Ft Forced Air Laboratory Oven is a large-capacity drying and sterilization oven designed for industrial laboratories, pharmaceutical facilities, and medical device manufacturing environments. Featuring a 316L stainless steel chamber, this oven provides exceptional corrosion resistance and cleanliness for applications requiring high-purity processing.

Using forced-air convection heating and microcontroller-based temperature control, this industrial laboratory oven delivers excellent temperature uniformity and dependable heating performance across the entire chamber. The built-in memory function automatically restores previous operating settings after power interruptions, allowing the oven to resume operation once power returns.

With an expansive 22 cubic foot chamber capacity, this oven is ideal for large batch drying, sterilization, and temperature-controlled processing in demanding laboratory and industrial applications.

Key Features

316L Stainless Steel Chamber

  • High-grade 316L stainless steel interior

  • Superior corrosion resistance for pharmaceutical and laboratory applications

  • Ideal for sterilization, drying, and high-purity environments

Precision Digital Temperature Control

  • Microcontroller-based control improves temperature accuracy and stability

  • Built-in temperature calibration capability

  • Digital interface provides precise temperature control

Forced-Air Convection Heating

  • Forced-air circulation distributes heat evenly throughout the chamber

  • Ensures consistent temperature uniformity across all samples

  • Gentle downward airflow reduces disturbance to materials

Memory Retention Function

  • Automatically restores previous operating settings after power loss

  • Allows continuous laboratory processes without manual reconfiguration

Temperature Alarm System

  • Alarm triggers when temperature moves outside the desired range

Moisture Control

  • Adjustable dual moisture escape ports allow humidity to vent during drying processes

Heavy-Duty Laboratory Construction

  • Corrosion-resistant 316L stainless steel chamber

  • Double-glazed observation window allows safe monitoring of samples

Integrated Safety Protection

  • Overheat protection system automatically shuts off power if temperature exceeds limits or sensor failure occurs

Ideal Applications

  • Medical device drying and sterilization

  • Pharmaceutical manufacturing processes

  • Laboratory materials testing

  • Industrial research and development

Technical Specifications

Electrical Requirements

  • Voltage: 220V

  • Frequency: 50/60 Hz

  • Phase: Single Phase

  • Current: 31.8A

  • Power Consumption: 7000 Watts

Note: This model is available in 220V single phase only.

Chamber

  • Capacity: 22 Cubic Feet

  • Interior Dimensions: 31" × 31" × 39" (W × D × H)

  • Chamber Material: 316L Stainless Steel

Temperature Control

  • Temperature Range: Ambient to 250°C

  • Controller: Digital Microcontroller

  • Timer Range: 1 – 9999 minutes

Air Circulation

  • Forced-air convection heating system

  • Designed for uniform heat distribution throughout the chamber

Moisture & Access Ports

Moisture Escape Ports

  • Two adjustable 2" diameter moisture vents located on top of oven

Access Port

  • 2" diameter access port with removable cover

Dimensions & Weight

  • Unit Dimensions: 37.5" × 40" × 57"

  • Shipping Dimensions: 45" × 45" × 64"

  • Unit Weight: 510 lbs

  • Shipping Weight: 700 lbs

Shelf System

Included Shelves

  • 2 Stainless Steel Wire Shelves Included

Shelf Capacity

  • Maximum load capacity per shelf: 15 kg

  • Shelf spacing: 2 inches between racks

Additional shelves available separately.

Materials & Construction

  • Chamber Interior: 316L Stainless Steel

  • Observation Window: Double-glazed tempered glass

  • Exterior Housing: Industrial laboratory-grade construction

Safety Features

  • Overheat protection system

  • Automatic shutdown if temperature exceeds safe limits

  • Sensor failure protection

Compliance & Certifications

  • CE Certified

  • ETL tested to UL & CSA standards (optional)

What's Included

  • 1 × Across International 22 Cu Ft Forced Air Oven (316L Chamber)

  • 2 × Stainless Steel Wire Shelves

  • 4 × L-Brackets

  • 1 × User Manual

Warranty

  • 1 Year Manufacturer Warranty
