Across International FO19240-316L Ai 250°C 8 Cu Ft 13 Shelves Max Forced Drying Oven With 316L Chamber 220V
Across International FO19240-316L Ai 250°C 8 Cu Ft 13 Shelves Max Forced Drying Oven With 316L Chamber 220V
Across International FO19240-316L Ai 250°C 8 Cu Ft 13 Shelves Max Forced Drying Oven With 316L Chamber 220V
Roll over image to zoom in Click on image to zoom
Across International FO19240-316L Ai 250°C 8 Cu Ft 13 Shelves Max Forced Drying Oven With 316L Chamber 220VAcross International FO19240-316L Ai 250°C 8 Cu Ft 13 Shelves Max Forced Drying Oven With 316L Chamber 220VAcross International FO19240-316L Ai 250°C 8 Cu Ft 13 Shelves Max Forced Drying Oven With 316L Chamber 220V

Across International FO19240-316L Ai 250°C 8 Cu Ft 13 Shelves Max Forced Drying Oven With 316L Chamber 220V

Across International
Price:
$3,590.00

Description

The Across International 8 Cu Ft Forced Air Laboratory Oven is a high-capacity drying and sterilization oven designed for laboratory, medical, and research environments. Featuring a 316L stainless steel chamber, this oven provides exceptional corrosion resistance and cleanliness for applications such as medical device drying, sterilization, and laboratory sample preparation.

Using forced-air convection heating combined with microcontroller-based temperature control, this laboratory oven delivers excellent temperature uniformity and dependable heating performance. The integrated memory retention function restores previous settings after power interruptions, allowing the oven to automatically resume operation when power is restored.

With its large 8 cubic foot chamber, this oven is ideal for laboratories requiring higher batch capacity and consistent temperature-controlled drying or sterilization processes.

Key Features

316L Stainless Steel Chamber

  • High-grade 316L stainless steel interior

  • Superior corrosion resistance for medical and laboratory environments

  • Ideal for sterilization and high-purity drying applications

Precision Digital Temperature Control

  • Microcontroller-based control enhances temperature precision and stability

  • Built-in temperature calibration capability

  • Digital display for easy monitoring and control

Forced-Air Convection Heating

  • Forced-air circulation ensures uniform heat distribution throughout the chamber

  • Maintains consistent heating conditions for reliable laboratory processes

  • Gentle downward airflow minimizes disturbance to samples

Memory Retention Function

  • Automatically resumes previous settings after power loss

  • Helps maintain continuous laboratory operations

Temperature Alarm System

  • Alarm triggers when temperature moves outside the desired operating range

Moisture Control

  • Adjustable dual moisture escape ports allow humidity to vent during drying processes

Durable Laboratory Construction

  • Corrosion-resistant 316L stainless steel chamber

  • Double-glazed observation window for safe monitoring of samples

Integrated Safety Protection

  • Overheat protection automatically shuts down the oven if temperature exceeds safe limits or sensor failure occurs

Ideal Applications

  • Medical device drying and sterilization

  • Laboratory sample drying

  • Pharmaceutical and biotech laboratory applications

  • Materials testing and research processes

Technical Specifications

Electrical Requirements

  • Voltage: 208–240 VAC

  • Frequency: 50/60 Hz

  • Phase: Single Phase

  • Power Consumption: 3000 Watts

Note: This model is available in 220V single phase only.

Chamber

  • Capacity: 8 Cubic Feet

  • Interior Dimensions: 23" × 19" × 29.75" (W × D × H)

  • Chamber Material: 316L Stainless Steel

Temperature Control

  • Temperature Range: Ambient to 250°C

  • Controller: Digital Microcontroller

  • Timer Range: 1 – 9999 minutes

Air Circulation

  • Forced-air convection heating system

  • Designed for consistent temperature distribution throughout the chamber

Environmental Operating Conditions

  • Indoor use only

  • Maximum altitude: 2000 meters

  • Operating temperature: 5°C – 40°C

  • Maximum relative humidity: 80% up to 30°C, decreasing to 50% at 40°C

  • Mains voltage fluctuation tolerance: ±10%

Moisture & Access Ports

Moisture Escape Ports

  • Two adjustable 2" diameter moisture vents located on top of oven

Access Port

  • 2" diameter access port with removable cover

Dimensions & Weight

  • Unit Dimensions: 30" × 28" × 46.5"

  • Shipping Dimensions: 34" × 34" × 50"

  • Shipping Weight: 300 lbs

Shelf System

Included Shelves

  • 2 Stainless Steel Wire Shelves Included

Shelf Capacity

  • Maximum Rack Capacity: 13 shelves

  • Shelf Spacing: 2 inches between racks

Additional shelves available separately.

Materials & Construction

  • Chamber Interior: 316L Stainless Steel

  • Observation Window: Double-glazed tempered glass

  • Exterior Housing: Laboratory-grade metal construction

Safety Features

  • Overheat protection system

  • Automatic shutdown if temperature exceeds safe limits

  • Sensor failure protection

Compliance & Certifications

  • CE Certified

  • ETL tested to UL & CSA standards (optional)

What's Included

  • 1 × Across International 8 Cu Ft Forced Air Oven (316L Chamber)

  • 2 × Stainless Steel Wire Shelves

  • 4 × L-Brackets

  • 1 × User Manual

Warranty

  • 1 Year Manufacturer Warranty
