Description
The Across International 0.5 Cu Ft Forced Air Laboratory Oven is a compact, precision-controlled drying oven designed for laboratory, medical, and research environments. Featuring a 316L stainless steel chamber, this oven provides superior corrosion resistance and cleanliness for sensitive applications such as medical device drying, sterilization, and laboratory sample preparation.
Equipped with forced-air circulation and digital microcontroller temperature control, the oven delivers highly uniform heating and accurate temperature regulation throughout the chamber. The built-in memory function automatically restores settings after power interruptions, ensuring reliable operation and minimizing downtime.
Designed for benchtop use, this compact laboratory oven provides dependable drying and heating performance for a wide range of laboratory processes.
Key Features
316L Stainless Steel Chamber
-
High-grade 316L stainless steel interior
-
Excellent corrosion resistance for laboratory and medical applications
-
Ideal for sterilization, drying, and sensitive material processing
Precision Digital Temperature Control
-
Microcontroller-based system improves temperature accuracy and uniformity
-
Built-in temperature calibration capability
-
LCD digital temperature display
Forced-Air Circulation System
-
Forced-air circulation distributes heat evenly throughout the chamber
-
Maintains stable and uniform temperature conditions
-
Gentle downward airflow minimizes disturbance to samples
Memory Function
-
Automatically restores previous settings after power loss
-
Allows uninterrupted operation after power is restored
Temperature Alarm System
-
Adjustable alarm triggers if temperature moves outside the desired range
Moisture Control
-
Adjustable moisture escape port
-
Helps remove humidity during drying processes
Durable Laboratory Construction
-
Corrosion-resistant stainless steel interior
-
Double-glazed observation window for safe sample monitoring
Integrated Safety Protection
-
Overheat protection system automatically shuts down the oven if temperature exceeds limits or if sensor failure occurs
Ideal Applications
-
Medical device drying
-
Laboratory sample preparation
-
Sterilization processes
-
General laboratory heating applications
Technical Specifications
Electrical Requirements
-
Voltage: 110VAC
-
Frequency: 60Hz
-
Phase: Single Phase
-
Power Consumption: 500 Watts
Chamber
-
Capacity: 0.5 Cubic Feet
-
Interior Dimensions: 9.25" × 8.75" × 10" (W × D × H)
-
Material: 316L Stainless Steel
Temperature Control
-
Temperature Range: Ambient to 200°C
-
Controller: Digital Microcontroller
-
Heating Elements: Located at the rear of the oven
-
Timer Range: 1 – 9999 minutes
Air Circulation
-
Forced-air convection system
-
Gentle downward airflow along chamber walls
-
Improves heat distribution and sample protection
Moisture & Access Ports
-
Moisture Escape Port:
-
2" diameter adjustable port located on top of the oven
-
-
Optional Access Port:
-
2" diameter with removable cover
-
Dimensions & Weight
-
Unit Dimensions: 21" × 17.25" × 17"
-
Shipping Dimensions: 26" × 23" × 22"
-
Unit Weight: 55 lbs
-
Shipping Weight: 100 lbs
Shelf System
Included Shelves
-
2 Stainless Steel Wire Shelves Included
Shelf Capacity
-
Maximum Rack Capacity: 4 Shelves
-
Shelf Spacing: 2 inches between racks
Additional shelves available separately.
Materials & Construction
-
Chamber Material: 316L Stainless Steel
-
Observation Window: Double-glazed tempered glass
-
Exterior Construction: Laboratory-grade metal housing
Safety Features
-
Overheat protection system
-
Automatic shutdown if temperature exceeds safe limits
-
Sensor failure protection
Compliance & Certifications
-
ETL tested to UL & CSA standards (optional certification)
-
CE Certified
What's Included
-
1 × Across International 0.5 Cu Ft Forced Air Oven (316L Chamber)
-
2 × Stainless Steel Wire Shelves
-
4 × L-Brackets
-
1 × 110V 3-Prong Power Cord
-
1 × User Manual
Warranty
-
1 Year Manufacturer Warranty
