Across International
Price:
$1,350.00

Description

The Across International AT09e ECO Vacuum Drying Oven is a compact, high-performance laboratory vacuum oven designed for precise drying, degassing, curing, and solvent removal applications. Featuring a 0.9 cubic foot stainless steel chamber, this desktop vacuum oven provides consistent vacuum pressure and temperature control to significantly reduce drying times while improving product quality.

Built with a dual-layer tempered glass observation window, 3-sided heating, and a 3rd generation PID temperature controller, the AT09e delivers exceptional temperature stability and reliable performance for laboratory, research, pharmaceutical, and extraction environments.

Every Across International vacuum oven undergoes two separate 24-hour vacuum leak tests and is fully quality-controlled in New Jersey or Nevada before shipping, ensuring dependable performance and long-term durability.

Key Features

Precision Vacuum Drying Performance

  • Maintains consistent vacuum pressure to significantly reduce drying and degassing times

  • Ideal for oil extract curing, solvent removal, and laboratory drying applications

3-Sided Heating System

  • Left heater: 400W

  • Right heater: 400W

  • Bottom heater: 700W

  • Provides uniform heat distribution for faster and more efficient processing

Advanced Temperature Control

  • 3rd generation microcomputer PID controller

  • Low proportional gain for highly stable temperature regulation

  • Temperature range: Ambient to 150°C (302°F)

Dual-Layer Safety Observation Window

  • ½" tempered safety glass

  • Allows clear monitoring of samples while maintaining safe chamber pressure

Industrial Grade Stainless Steel Chamber

  • Easy-to-clean interior

  • Corrosion resistant and durable for long-term lab use

Heavy Duty Thermal Insulation

  • 3” insulation layer reduces heat loss and keeps exterior surface temperatures lower

High Accuracy Vacuum Monitoring

  • Oil-filled mechanical vacuum gauge for more accurate readings

  • Designed to minimize shipping damage and extend gauge life

Built-In Safety Protection

  • Integrated circuit breaker

  • Overheat shutoff protection

  • Alarm notification if oven shuts down due to out-of-range temperature

Fast US Shipping & Support

  • Ships from New Jersey or Nevada

  • US-based phone and email support available within 30 minutes

Technical Specifications

Electrical Requirements

  • Voltage: 110V or 220V ±10%

  • Frequency: 60Hz

  • Phase: Single Phase

  • Power Consumption: 1,500 Watts

Chamber

  • Capacity: 0.9 Cubic Feet

  • Interior Size: 12" x 12" x 11"

  • Material: Stainless Steel

Temperature Control

  • Controller: 3rd Gen Microcomputer PID

  • Temperature Range: Ambient to 150°C

  • Display: Fahrenheit or Celsius

  • Temperature Uniformity: ±5% of setpoint

  • Warm-up Time: ~80 minutes to 480°F

  • Timer Range: 1 – 9999 minutes

Vacuum System

  • Ultimate Vacuum Level: Better than 500 microns / millitorr

  • Mechanical Gauge Range: 0 – 30 inHg

  • Vacuum Port: KF25 Flange

  • Vent Port: 1/4" Ball Valve

  • Vacuum Pump: Sold Separately

Dimensions & Weight

  • Unit Dimensions: 23.4" x 17.25" x 19"

  • With Handle & Port: 23.4" x 20" x 19"

  • Shipping Dimensions: 29" x 29" x 29"

  • Unit Weight: 85 lbs

  • Shipping Weight: 170 lbs

Shelving System

  • 4 Aluminum Slide-In Shelves Included

  • Maximum Capacity: 8 Shelves

  • Shelf Size: 11.5" x 11.25"

  • Maximum Total Shelf Area: ~7 sq ft

  • Shelf Spacing: 1 inch

Materials & Construction

  • Chamber Interior: Stainless Steel

  • Door Gasket Material: Silicone or Viton

  • Observation Window: ½" Tempered Safety Glass

  • Interior Lighting: White LED Lighting

Compliance & Manufacturing Standards

Manufactured in accordance with:

  • ISO 9001:2000

  • ISO 12100-1:2003

  • ISO 12100-2:2003

  • EN1050:1996

  • EN294:1992

  • EN60204-1:2006

  • CE Electrical Compliance

What's Included

  • 1 × Across International AT09e Vacuum Oven

  • 4 × Aluminum Shelves

  • 1 × KF25 Quick Clamp and Centering Ring

  • 1 × Quick Disconnect Vent Fitting (Pre-installed)

  • 1 × LED Light Cable

  • 1 × User Manual

Warranty

  • 1 Year Manufacturer Warranty

  • Lifetime US-Based Parts & Service Support

Important Operating Instructions

Before initial use, operate the oven at 200°C (400°F) without vacuum for 15 minutes to burn off any manufacturing residue.

Important Safety Notice
Never leave the oven unattended while operating. Across International is not responsible for loss of material inside the oven.
